17. Old German domeback  (624)  @   250 euros

Old German bowlback mandola

This is an old, German bowl-back mandolin from the early to mid 20th century. It is in good condition after minimal restoration. There is a head label which reads…

Arcus

This instrument is now fully restored. The top is sound with NO repairs. It has a 13-piece back in stained maple with one seam repair. It has the original fingerboard, with relevelled original frets. The tuners, bridge and tail are original, though the bridge has been remodelled to allow compensation. The instrument top has been lightly refinished with Tru-oil for protection, otherwise it retains its original finish. It has been restrung with phosphor bronze strings, and is now playing well with a full, round sound with good sustain and volume. It has an easy playing action.

Other than cleaning, I have repaired as follows… 1) repaired an open seam in the back; 2) remodelled the original bridge to add a bone saddle; 3) refinished the top with Tru-oil; 4) levelled the original frets; 5) replaced a missing tuner button; and 6) strung and set up.



Mandola Specifications (In Millimetres)

Overall Length of Mandolin

750mm

Width of mandolin at widest point

260mm

Approx. Depth of mandolin

200mm at bridge.

Finish

Original finish throughout (some small scuffs) with Tru-oil on the top.

Belly wood

Good quality, close-grained, book-matched, spruce top with NO repair. Top sealed with a coat of Tru-oil.

Scratch plate

Floral with lots of mop, good condition.

Sound hole

Ovaloid, approx. 70 x 40mm.

Back and sides

13-piece, stained, maple bowl. 1 seam repair.

Neck and Head

Single-piece, head and neck in good condition.

Fingerboard

Original with 18 relevelled brass frets. MOP position markers at 5, 7 and 12.

Machine heads

Original steel and brass tuners, 1 new button. All working.

Tailpiece

Original in steel, with 8 string hooks.

Bridge/tensioner

Remodelled original new with bone saddle.

Scale Length Bridge to nut

Scale of 420mm

C string height at bridge

9mm

A string height at bridge

9mm

12th fret to bottom of C string (Action)

2.25mm

12th fret to bottom of A string (Action)

2mm

Width of fretboard at nut

34mm

Width of fretboard at widest point

48mm


Larger Photos can be sent on request
